Presonus StudioLive 32R 34-Input, 32-Channel Series III Stage Box & Rack Mixer


  • Our Price
  • $1,499.95
  • Regular price MSRP: $1,999.95




OUT OF STOCK BUT WE CAN GET IT
• Ship time varies by availability - C19 delays possible
• Order now to reserve yours ~ risk free


Get More Control On The Stage And In The Studio With The Presonus StudioLive 32R 34-Input, 32-Channel Series III Stage Box And Rack Mixer

PreSonus’ 32-channel Series III StudioLive 32R is both a versatile AVB stage box for StudioLive Series III consoles and the most powerful rack mixer in its class. It can operate as a simple stage box or as a combined stage box/monitor mixer, including remote control of the preamps and phantom power from the Series III console. As with Series III consoles, it’s fully recallable and features a plug-in-style signal-processing workflow with vintage-style EQ and compression options on every channel; 16 FlexMixes that can be Aux, Subgroup, or Matrix mixes; 4 fixed subgroups; 6-band fully parametric EQ on all mix outputs; and built-in AVB networking. In addition to 40x40 USB and 55x55 AVB recording interfaces, the StudioLive 32R features an onboard stereo SD recorder.

THE PERFECT PARTNER FOR A STUDIOLIVE SERIES III CONSOLE

The StudioLive 32R Series III rack mixer is a perfect partner for your StudioLive Series III console/recorder, serving as either a simple stage box or a combination stage box and monitor mixer. Since Series III rack mixers and consoles can network using AVB, you can connect your StudioLive 32R to a Series III front-of-house console with one lightweight CAT5e or CAT6 Ethernet cable, eliminating the need for a heavy, expensive copper snake-and the signal degradation that goes with long analog cable runs. You can even remote control the StudioLive 32R’s preamps and phantom power from your networked Series III console. In stage box + monitor mixer mode, the StudioLive 32R not only serves as an excellent networked stage box, it is a full blown monitor mixer with far more processing and mixing power than any mixer in its class-all packed into just two rackspaces (2U).

THE MOST POWERFUL RACK MIXER IN ITS CLASS

When Presonus says the StudioLive Series III stage boxes and rack mixers are by far the most powerful rackmount digital mixers in their class, that’s no idle claim. The result of ten years of R&D, third-generation StudioLive Series III rack mixers are fully recallable, including remote-controlled XMAX preamps. Yet despite their extensive features, StudioLive Series III rack mixers actually improve upon PreSonus’ legendary ease of use while letting you customize their workflow and operations in software to fit the way you work. The coveted StudioLive sound is better than ever, including third-generation Fat Channel processing, re-engineered from the ground up, and vintage-style EQs and compressors. Add built-in AVB networking, multitrack recording via USB 2.0 and AVB, onboard stereo recording to SD Card, and a complete suite of software, and you have a mixing and recording powerhouse that’s equally formidable as a stage box/monitor mixer, as a rackmount front-of-house mixer controlled from a touchscreen computer or tablet, and as the heart of your studio.

CREATE BUSES AND GROUPS TO SUIT YOUR WORKFLOW WITH FLEXMIXES.

Don’t you hate it when you’re setting up for a show and find you have an unused subgroup-but you’re short one monitor mix? That’s not a problem anymore, thanks to 16 FlexMixes that can be individually designated as aux, subgroup, or matrix mixes. These 16 FlexMixes are in addition to the 4 fixed subgroups giving you a total of 20 mix buses, not counting the main mix and solo buses. Presonus also provided 24 Filter DCAs so you can more easily and flexibly control groups of channels. These are only a few of the many ways you can customize your StudioLive Series III rack mixer exactly to your needs and workflow.

SUPERIOR SOUND

Co

  • 32-channel AVB stage box for StudioLive Series III consoles
  • Simple stage box mode
  • Stage box + monitor mixer mode with control of preamps and phantom power from StudioLive Series III console
  • Fully recallable, 32-channel, Series III digital rack mixer
  • 34 total inputs
  • 32 locking combo mic/line channel inputs with recallable XMAX Class A mic preamps
  • 2 RCA line-level channel inputs (Ch. 31-32)
  • 16 1/4" TRS FlexMix outputs
  • 2 XLR main outputs (left/right)
  • Scene management with Scene Safe
  • 16 FlexMixes (Aux mixes, Subgroups, or Matrix mixes)
  • 4 dedicated subgroups
  • 4 internal effects buses (combination of reverbs and delays with modern and vintage options)
  • Fat Channel processing with vintage EQ and Compressor modes available on every channel and A/B compare
  • 40x40 USB 2.0 recording interface and 55x55 AVB recording interface
  • Onboard stereo recording to SD card
  • Complete solution: Includes UC Surface touch-control software for Mac, Windows, iPad, and Android; Capture live-recording software and Studio One Artist DAW for Mac and Windows; compatible with free QMix-UC personal monitoring control for iPhone/iPod touch, and Android


MICROPHONE PREAMPLIFIER

  • Input Type: Combo locking XLR mic-1/4" TRS line
  • Frequency Response to Main Output (at unity gain): 20-20 kHz, +/-0.5 dBu
  • Input Impedance: 1 k Ohms
  • THD to Main Output: <0.005%, +4 dBu, 20-20 kHz, unity gain, unwtd
  • S/N Ratio to Main Output (Ref = +4 dB, 20 kHz BW, unity gain, A-wtd): 94 dB
  • Common Mode Rejection Ratio (1 kHz at unity gain): 65 dB
  • Gain Control Range (±1 dB): 0 dB to +60 dB
  • Maximum Input Level (unity gain): +12 dBu
  • Phantom Power (+/- 2 VDC): 48 VDC, switchable per channel

UNBALANCED INPUTS (CH. 31-32)

  • Type: RCA Female, unbalanced (stereo pair)
  • Maximum Input Level: +12 dBu, ±0.5 dBu

MAIN OUTPUTS

  • Type: XLR Male, balanced
  • Maximum Output Level: +24 dBu, ±0.5 dBu
  • Output Impedance: 100 Ohms

MIX OUTPUTS

  • Type: 1/4" TRS Female, balanced
  • Maximum Output Level: +18 dBu,  +/- 0.5 dBu
  • Output Impedance: 100 Ohms

HEADPHONE OUTPUT

  • Type: 1/4" TRS Female, active stereo
  • Maximum Output: 100 mW/ch. @ 60 Ohms load
  • Frequency Response: 20 Hz - 20 kHz (+/- 0.5 dB)
  • THD+N: 0.01%, 1 kHz, max gain, 20 Hz BW, unwtd
  • S/N Ratio: 96 dB, 1 kHz, max gain, 20 Hz BW, unwtd

SYSTEM CROSSTALK

  • Input to Output: -90 dB (Ref = +4 dBu, 20 Hz-20 kHz, unwtd)
  • Adjacent Channels: -87 dB (Ref = +4 dBu, 20 Hz-20 kHz, unwtd)

DIGITAL AUDIO AND CONTROL

  • ADC Dynamic Range: 115 dB (A-wtd, 48 kHz)
  • DAC Dynamic Range: 115 dB (A-wtd, 48 kHz)
  • USB Recording Port: USB 2.0, Type-B
  • AES/EBU Output: XLR Male
  • Network Control Port: RJ-45
  • AVB Audio Network Port: Ethercon
  • Internal Processing: 32-bit, floating point
  • Sampling Rate: 48 kHz (44.1 kHz coming soon)
  • A/D/A Bit Depth: 24
  • Reference Level for 0 dBFS: +18 dBu
  • Total System Latency: 1.9 ms (local routing, analog in-analog out, all processing active)

CLOCK

  • Jitter: <20 ps RMS (20 Hz - 20 kHz)
  • Jitter Attenuation: >60 dB (1 ns in, 1 ps out)

POWER / ENVIRONMENTAL

  • Connector: IEC
  • Input-Voltage Range: 90 to 230 VAC (±10%)
  • Power Requirements (continuous): 85W
  • Recommended Ambient Operating Temperature: 0 Degree to 40 Degrees Celsius / 32 Degrees to 104 Degrees Fahrenheit

Manufacturer: Presonus Audio
Model: STUDIOLIVE 32R
Warranty: See manufacturer website for details
SKU: I492235-N-0
UPC: #673454005916
Listing ID: NA86135
