Dynacord C3600FDI DSP 2 x 1800-Watt Power Amplifier

Low Cost, High Performance - The Dynacord C3600FDI DSP 2 x 1800-Watt Power Amplifier

Dynacord C Series amplifiers are dedicated installation DSP amplifiers optimized for 24/7 operation. Besides low impedance operation (2 Ohms, 4 Ohms or 8 Ohms) C3600FDi can drive 100 V loudspeaker lines directly (‑1.5 dB) without output transformers. Integrated digital signal processing provides access to professional speaker processing with FIR Drive technology. C Series amplifier utilize Class A/B resp. Class H topologies, which provide market leading acoustic performance and reliability. The connectivity is optimized for the needs of fixed install applications. For low cost of ownership a power saving standby mode is available. A front panel LC display allows local control and supervision of the amplifier. An intuitive system control software allows fast system setup, flexible system control and comprehensive supervision.

• Professional DSP amplifier for live and mobile application
• Fully integrated professional speaker processing with FIR drive technology
• Market-leading acoustic performance and rock solid reliability
• Intuitive, simplified set-up, control and operation in SONICUE sound system software with firmware 2.0

SPECIFICATIONS

• Maximum RMS Voltage Swing THD = 1%, 1 kHz: 96.6 V
• Voltage Gain Ref.1 kHz: 32.0 dB
• THD at 900 W/4 Ω MBW = 80 kHz, 1kHz: < 0.05%
• IMD-SMPTE, 60 Hz, 7 kHz: < 0.1%
• DIM30,3.15 kHz, 15 kHz: < 0.05%
• Maximum Input Level: +21 dBu
• Crosstalk ref. 1 kHz, at 100W/4 Ω: < -80 dB
• Frequency Response, ref. 1 kHz: 10 Hz to 21 kHz (±1 dB)
• Input Impedance, Active Balanced: 20 k Ω
• Signal to Noise Ratio Amplifier, A-weighted, ref to Max. Output Power@ 8 Ω: >109 dB
• Output Noise, A-weighted: < -68 dBu
• Output Stage Topology: Class H
• Power Requirements: 240 V, 230 V, 120 V or 100 V; 50 Hz to 60 Hz (factory configured)
• Power Consumption ⅛ Maximum Output Power @ 4 Ω: 850 W
• Mains Fuse: 240 V/230 V: T15AH; 120 V/100 V: T30AH
• Protection: Audio limiters, high temperature, DC, HF, Back-EMF, Peak current limiters, Inrush current limiters, Turn on delay
• Cooling: Front-to-rear, 3-stage-fans
• Ambient Temperature Limits: +5°C to +40°C (40°F to +105°F)
• Safety Class: I
• Color: Black
• Weight: 18.2 kg (40.1 lbs.)
• Remote Power ON/GPIO: Power remote via switch, delay time selectable Floating relay contacts (show protect mode) Inputs for preset selection
• Signal Processing: FIR filters, audio limiters, output and array** delay, 10-band** user PEQ, 5-band array PEQ** per channel, load impedance
