Electro-Voice ELX200-12 12" Passive Loudspeaker

The Electro-Voice ELX200-12 12" Passive PA Speaker is Designed to Deliver an Unprecedented Combination of Sound Quality, Portability, and Durability at Its Price Point

Every aspect of ELX200 is designed for ideal results as part of the whole - the acoustical, electrical and mechanical components all work together seamlessly. It features a low profile form factor designed with a high-spec composite enclosure to balance weight, manageability, as well as structural integrity. Also present: Signal Synchronized Transducers (SST) waveguide concept. EV's industry-leading quality and testing procedures yield efficient transducer design and meaningful specs, resulting in components that deliver accurate, linear response at the system's highest output levels. Translation: loud and clear all the way up to the limit. Unified in one of the strongest full-range composite enclosures ever built by EV. The ELX200 is established as the new benchmark for toughness - both acoustically and physically; maximum efficiency with maximum toughness.

• 1200 W (peak), 128 dB peak SPL system that is reliability verified with over 500 hours of abuse testing and endurance testing to 4x typical industry practices
• 1.4 inch DH-1L (1 inch exit) titanium compression driver for extended transparent high-frequency response
• High-output EVS-12M woofer designed to exacting specifications for superior durability and exceptional low-frequency reproduction
• EV-patented Signal Synchronized Transducers (SST) waveguide design provides precise and consistent coverage, minimal distortion, and maximized acoustical loading
• Professional-grade hardware: three M10 threaded mounting points for forged eyebolts, integrated pole-mounts and the proven ZLX three-handle design for easy lifting

SPECIFICATIONS

• Suspension: 3x M10 suspension points
• Minimum Impedance: 7.5Ω
• HF Transducer: DH-1L 1-inch titanium compression driver
• Speaker Type: Full-Range
• Woofer Size: 12 inch
• Frequency Response (-3 dB): 77 Hz - 17 kHz
• Frequency Range (-10 dB): 51 Hz - 20 kHz
• Max. SPL/1m (calc): 128 dB
• Coverage (Nominal -6 dB): H 90° x V 60°
• LF Transducer: EVS-12M 300 (12 inch)
• Power Rating: 1200 W
• Crossover Frequency: 1.7 kHz
• Connector Type: Dual NL4
• Enclosure Material: Polypropylene composite
• Grille: 18 AWG steel with powdercoat
• Recommended High-Pass Frequency: 50 Hz
• Dimensions (H x W x D): 24.76 x 14.29 x 13.54 inch / 629 x 363 x 344 mm
• Net Weight: 33.51 lb / 15.2 kg
• Shipping Weight: 37.7 lb / 17.1 kg
• Nominal Impedance: 8Ω
• Axial Sensitivity (SPL, 1 W @ 1 m): 93 dB
• Power Handling (Continuous / Peak): 300 W / 1200 W
