Electro-Voice ZXA1-90B-120V 8" Compact Powered Loudspeaker

  • Our Price
  • $499.00
  • Regular price MSRP: $663.00


Get Incredible Audio Quality And Reliability With The Electro-Voice ZXA1-90B-120V 8" Compact Powered Loudspeaker

Electro-Voice engineers have raised the bar for portable sound once again, adding to the award-winning ZX loudspeaker family with the new Electro-Voice. the self-powered version of the best-selling ZX1 compact two-way loudspeaker. The Electro-Voice ZXA1 is powered by an 800 watt amplifier module derived from EV's world-tour-class Tour Grade series amplifiers with audio quality and reliability proven at the very highest levels.

  • Integrated 800 watt power amplifier
  • Bi-amplified design with transducer protection
  • EV8L 8” high-output LF transducer
  • DH2005 1” exit true compression driver
  • 90° x 50° coverage pattern
  • Rotatable horn design
  • 126 dB maximum SPL
  • Selectable high-pass filter for use with subwoofers
  • Line and microphone inputs
  • Integral monitor angle on enclosure
  • Built-in pole mount
  • Lightweight (20 lbs) with integral handle for easy carrying


  • Amplifier Power: 800Watts (RMS)
  • Available Color: Black
  • Coverage (Nominal -6 dB) H: 90(Rotatable)
  • Coverage (Nominal -6 dB) V: 50(Rotatable)
  • Crossover Frequency: 1800Hz
  • Depth: 10.4" (264mm)
  • Enclosure Material: High Impact Polystyrene Composite
  • Family: Zx/ZxA
  • Flying: No
  • Frequency Response (-10 dB): 48 - 20000Hz (Full Range Mode)
  • Frequency Response (-3 dB): 60 - 20000Hz (Full Range Mode)
  • Grille: Polyester Powder Coated, 18GA Galvanized Steel
  • Height: 18" (457mm)
  • HF Transducer: 1.25" DH2005
  • Input Connections: XLR and TRS Combo; XLR with Independent Gain
  • LF Transducer: 8" EV8L
  • Max. SPL/1m (calc): 126dB
  • Power Rating: 800W
  • Power Requirement: 120V: 95V - 132V, 50 - 60 Hz, 0.6A 230V:190V - 264V, 50 - 60 Hz, 0.4A
  • Powered or Passive: Powered
  • Recommended High-Pass Frequency: 36Hz (User Selectable)
  • Shipping Weight: 22.5lbs (10.2kg)
  • Speaker Type: Full-Range, powered monitors, powered speakers, two-way, wedges
  • Weatherized: No
  • Weight Net: 19lbs (8.62kg)
  • Width: 11.1" (282mm)
  • Woofer Size: 8"

Manufacturer: Electro-Voice
Model: ZXA1-90B-120V
Warranty: See manufacturer website for details
SKU: I243697-1-B
