PreSonus StudioLive Series III SE 32R Digital Rack Mixer
MSRP: $191900
Couldn't load pickup availability
About Inventory Status
About Inventory Status
Questions? Call or text us at 301-946-8808.
♫ In stock: It is in stock and available to ship or pickup. Apparel must be shipped from another location and is not available for in-store pickup. We can usually ship or have these items available for pickup by the next business day if they don't require inspection, special handling, or setup. Our pickup location is 11151 Veirs Mill Rd. Silver Spring, MD 20902.
📆 Preorder: It is on the way to our warehouse. We can't predict when preorder items will arrive due to current supply chain issues. If you place an order for one of these items someone will contact you to estimate the delivery date.
❓ Out of stock: We don't currently have it available but you're not out of luck yet. We still may be able to get it. If you order one of these items we will contact you with an estimated fulfillment date. You have the option to cancel the order if you change your mind.
❔ Special order: The item is so special that it needs to be custom ordered for you. Some of these items are works of art and have to be made individually. Orders for special order items must be prepaid and we cannot accept cancellations or refunds.
█ Sold out: We don't think we can get this item because it was either discontinued by the manufacturer or was limited in quantity. If you want or need this item call or text us. Sometimes we can help you track down the item through other sources or help you find something similar.
About Item Conditions
About Item Conditions
Questions? Call or text us at 301-946-8808.
New: The item is brand new as received from the manufacturer with a full manufacturer warranty. Instruments such as guitars, snare drums, drum kits, brass and woodwind instruments may be opened for photography and quality control inspection and may not be in a factory sealed box.
Mint or Open Box: The item may have been opened and tested but has been repackaged. The original packaging may have superficial issues but the item itself and any originally included accessories are in perfect, like new condition.
Display Model: These items are so cool that we put them on display in our legendary shop. The condition is brand new as received from the manufacturer with manufacturer warranty. Rest assured, these items undergo a very careful inspection before shipping.
Demo: These items have been on our sales floor for demo purposes and will likely show signs of use. The original packaging may no longer be included, but you can be assured that you are receiving an awesome item and an awesome price.
Used: The item is used. These item may have varying degrees of wear. Please read the description for information about the condition of the item. Used items do not carry a warranty.
B or C Stock: Factory refurbished. These items were purchased from the manufacturer in a refurbished condition. They will show some cosmetic issues, but nothing that would impact performance. Being that these are sealed from the manufacturer, we generally do not open these to photograph the cosmetic issues. They are guaranteed to work and may have a limited warranty or you may purchase an extended warranty in some cases. Please see the listing description for item specific information.
Description
Description
Get Scalable Live Mixing and Recording with the PreSonus StudioLive SE 32R Digital Rack Mixer
The PreSonus StudioLive SE 32R Digital Rack Mixer is a 40-channel rack mixer built for live mixing, in-ear monitor rigs, stagebox applications, and recording. With 32 onboard XMAX-R recallable preamps, 16 FlexMixes, 4 dedicated subgroups, 4 FX mixes, and 24 DCAs, it delivers the routing flexibility and channel control needed for demanding stage and studio workflows.
- 40-channel digital rack mixer with 32 XMAX-R recallable preamps
- 16 FlexMixes configurable as aux, subgroup, or matrix mixes
- 4 dedicated subgroups and 4 FX mixes with stereo returns
- 24 DCA groups for precise control
- Continuously bidirectional 64x64 USB 2.0 audio interface
- Onboard stereo SD recording
- Capture integration with Virtual Soundcheck
- Milan-certified AVB networking for Series III ecosystems
- Per-channel source switching for Analog, USB, SD, and AVB
- Universal Control remote mixing and Offline Editor
- QMix-UC personal monitor mixing
- Standalone, monitor mixer, or stagebox modes
- Perpetual license for Fender Studio Pro included
The StudioLive SE 32R combines professional routing, flexible monitoring, and integrated recording tools in a compact rackmount format. Milan-certified AVB networking allows seamless integration with NSB stageboxes, EarMix 16M personal monitor mixers, and other StudioLive Series III mixers. Per-channel source switching and wireless control through Universal Control and QMix-UC give engineers and performers the flexibility to adapt quickly in live and installed sound environments.
For recording and playback, the SE 32R features a continuously bidirectional 64x64 USB 2.0 audio interface, onboard stereo SD recording, and Virtual Soundcheck with Capture software. Deep integration with Fender Studio Pro also helps simplify recording workflows with direct preamp control and seamless switching between onboard processing and Fat Channel XT plug-in processing.
SPECIFICATIONS
General
- Product Name: StudioLive SE 32R Digital Rack Mixer, Black, NA
- Series: StudioLive
- Color: Black
Electronics
- Headphone Jack: 1/4-inch TRS Active Stereo
- Phantom Power: +48 VDC (±2 VDC)
- Power Consumption: 35W continuous
- Voltage: 120V
- Voltage Requirements: 100-230 VAC, 50-60 Hz
Inputs
- Line Input Connection Type: RCA Female, Unbalanced (Stereo Pair)
- Line Inputs Maximum Level: +12 dBu, ±0.5 dBu
- Microphone Input Connection Type: Combo Locking XLR Mic - 1/4-inch TRS Line
- Microphone Preamp Common Mode Rejection Ratio: 65 dB (1 kHz at Unity Gain)
- Microphone Preamp Frequency Response: 20 Hz to 20 kHz (±0.5 dBu at Unity Gain)
- Microphone Preamp Gain Control Range: 0 dB to 60 dB (±1 dB)
- Microphone Preamp Input Impedance: 1 kΩ
- Microphone Preamp Maximum Input Level: +12 dBu (Unity Gain)
- Microphone Preamp Signal to Noise Ratio: 94 dB (Ref = +4 dB, 20 kHz BW, Unity Gain, A-Weighted)
- Microphone Preamp Total Harmonic Distortion: <0.005%, +4 dBu, 20 Hz to 20 kHz, Unity Gain, Unweighted
Outputs
- Headphone Outputs Frequency Response: 20 Hz to 20 kHz, ±0.5 dB
- Headphone Outputs Maximum Output: 100 mW/ch. @ 60Ω Load
- Headphone Outputs Signal to Noise Ratio: 96 dB, 1 kHz, Maximum Gain, 20 Hz BW, Unweighted
- Headphone Outputs Total Harmonic Distortion: 0.01%, 1 kHz, Maximum Gain, 20 Hz BW, Unweighted
- Line Outputs Connection Type: 1/4-inch TRS, Balanced
- Line Outputs Maximum Output Level: +18 dBu, ±0.5 dBu
- Line Outputs Output Impedance: 100 Ohms
- XLR Outputs Maximum Output Level: +24 dBu, ±0.5 dBu
- XLR Outputs Output Impedance: 100 Ohms
Digital Audio and Recording
- USB Recording Port: USB 2.0, Type-B
- Digital Audio Internal Processing: 32-bit floating point
- Digital Audio Bit Depth: 24-bit
- Digital Audio Dynamic Range: ADC 115 dB (A-Weighted, 48 kHz), DAC 115 dB (A-Weighted, 48 kHz)
- Digital Audio Reference Level for Zero dBFS: +18 dBu
- Digital Audio Total System Latency: 1.9 ms (local routing, analog in to analog out, all processing active)
- Recording File Format: Stereo WAV
- Supported Sample Rates: 48 kHz, 44.1 kHz
- SD Recorder Bit Depth: Recording 24-bit, Playback 16 or 24-bit
- SD Recorder Sampling Rate: 44.1 or 48 kHz
- Media Storage Capacity: SD Card 2 GB, SDHC Card 32 GB
- Supported Media Format: FAT16 formatted SD card, FAT32 formatted SDHC card
Networking and Ports
- Digital Audio AVB Audio Network Ports: Locking XLR, Ethernet
- Digital Audio Network Control Port: RJ-45
Performance
- Crosstalk (Adjacent Channels): -87 dB (Reference = +4 dBu, 20 Hz to 20 kHz, Unweighted)
Physical
- Product Height: 3.5 inches (90 mm)
- Product Width: 19 inches (483 mm)
- Product Depth: 12 inches (305 mm)
- Product Weight: 11.2 lbs (5 kg)
- Power Cable: IEC
- Recommended Ambient Operating Temperature: 0 to 40 degrees Celsius / 32 to 104 degrees Fahrenheit
Manufacturer: PreSonus Audio
Model: STUDIOLIVE SE 32R
SKU: I920832-N-2-WHXC
UPC: 673454014796
