RCF HDL-28A Dual 8" Active Two-Way Line Array Module - Black

The RCF HDL28-A is an Ultra-Compact Bi-Amped Two-Way Active Touring System for Small and Medium-Sized Events, both Indoors and Outdoors

The RCF HDL 28-A is a compact bi-amped 2-way active touring system for a wide range of applications, both indoors and outdoors, with an emphasis on vocal intelligibility. It features two 8-inch woofers and an impressive 3-inch titanium compression driver. The time coherent waveguide is the result of in-depth research and design. Following the HDL 30-A philosophy, the HDL 28-A shares the composite material cabinet, the zero-degree phase and ultra-linear amplitude response. The built-in 2200 watt class-D amplifier delivers excellent playback clarity and up to 135 decibels SPL max. The RCF HDL28-A features state of the art RCF transducers with lightweight neodymium magnets. Considering its acoustical power, it has a remarkably low weight for easy handling and flying. The HDL 36-AS is the ideal flyable bass complement for the HDL 28-A array system.

• 2200W Two Way Amplifier
• 135 dB Max SPL
• 48 kHz, 32 bit DSP processing
• RDNet Networked Management
• 2x 8-inch Neodymium Woofers, 2.5-inch voice coil
• 1.4-inch Titanium Compression Driver, 3.0-inch voice coil
• Exclusive FiRPHASE technology on-board
• 750 Hz Crossover Point

SPECIFICATIONS

Acoustical

• Frequency Response: 50 Hz - 20000 Hz
• Max SPL @ 1m: 135 dB
• Horizontal Coverage Angle: 100°
• Vertical Coverage Angle: 15°

Transducers

• Compression Driver: 1x 1.4" neo, 3.0" v.c
• Woofer: 2x 8" neo, 2.5" v.c

Inputs/Outputs

• Input Signal: bal/unbal
• Input Connectors: XLR, RDNet Ethercon
• Output Connectors: XLR, RDNet Ethercon
• Input Sensitivity: +4 dBu

Processor

• Crossover Frequencies: 750 Hz
• Protections: Thermal, RMS
• Limiter: Soft Limiter
• Controls: Preset, RDNet bypass
• RDNet: Yes

Power

• Total Power: 2200 W Peak, 1100 W RMS
• High Frequencies: 600 W Peak, 300 W RMS
• Low Frequencies: 1600 W Peak, 800 W RMS
• Cooling: Forced
• Connections: Powercon IN/OUT

Physical

• Cabinet/Case Material: PP Composite
• Hardware: Array fittings
• Handles: 2 Side
• Grille: Steel
• Color: Black
• Height: 11.57 inches / 294 mm
• Width: 22.4 inches / 569 mm
• Depth: 19.33 inches / 491 mm
• Weight: 45.42 lb / 20.6 kg
