Shure ULXD4D Digital Dual-Channel Wireless Receiver - G50 Band

by Shure
Original price $4,516.00
Original price $4,516.00 - Original price $4,516.00
Original price $4,516.00
Current price $2,903.00
$2,903.00 - $2,903.00
Current price $2,903.00

Spring Wireless Promotion Through March 31!

Save $323 - Was $3,226.00

♫ In stock
About Inventory Status


Questions?
Call or text us at 301-946-8808.

In stock: It is in stock and available to ship or pickup. Apparel must be shipped from another location and is not available for in-store pickup. We can usually ship or have these items available for pickup by the next business day if they don't require inspection, special handling, or setup. Our pickup location is 11151 Veirs Mill Rd. Silver Spring, MD 20902.

📆 Preorder: It is on the way to our warehouse. We can't predict when preorder items will arrive due to current supply chain issues. If you place an order for one of these items someone will contact you to estimate the delivery date.

Out of stock: We don't currently have it available but you're not out of luck yet. We still may be able to get it. If you order one of these items we will contact you with an estimated fulfillment date. You have the option to cancel the order if you change your mind.

Special order: The item is so special that it needs to be custom ordered for you. Some of these items are works of art and have to be made individually. Orders for special order items must be prepaid and we cannot accept cancellations or refunds.

█ Sold out: We don't think we can get this item because it was either discontinued by the manufacturer or was limited in quantity. If you want or need this item call or text us. Sometimes we can help you track down the item through other sources or help you find something similar.

About Item Conditions


Questions?
Call or text us at 301-946-8808.

New: The item is brand new as received from the manufacturer with a full manufacturer warranty. Instruments such as guitars, snare drums, drum kits, brass and woodwind instruments may be opened for photography and quality control inspection and may not be in a factory sealed box.

Mint or Open Box: The item may have been opened and tested but has been repackaged. The original packaging may have superficial issues but the item itself and any originally included accessories are in perfect, like new condition.

Display Model: These items are so cool that we put them on display in our legendary shop. The condition is brand new as received from the manufacturer with manufacturer warranty. Rest assured, these items undergo a very careful inspection before shipping.

Demo: These items have been on our sales floor for demo purposes and will likely show signs of use. The original packaging may no longer be included, but you can be assured that you are receiving an awesome item and an awesome price.

Used: The item is used. These item may have varying degrees of wear. Please read the description for information about the condition of the item. Used items do not carry a warranty.

B or C Stock: Factory refurbished. These items were purchased from the manufacturer in a refurbished condition. They will show some cosmetic issues, but nothing that would impact performance. Being that these are sealed from the manufacturer, we generally do not open these to photograph the cosmetic issues. They are guaranteed to work and may have a limited warranty or you may purchase an extended warranty in some cases. Please see the listing description for item specific information.

Educational & Government Sales Quotes

Click here to inquire about an educational or government quote and discover more about our Educational & Government Sales Division.


Cut through the Noise with the Shure ULXD4D Digital Dual-Channel Wireless Receiver - G50 Band

Frequency Band: G50 (470 - 534 MHz)

The Shure ULXD4D Dual Channel Digital Wireless Receiver offers two channels of uncompromising audio quality, RF signal stability and efficiency, and advanced setup features in a single rack unit. Rugged, yet lightweight and compact, the all-metal chassis houses two independent receivers, each with its own audio and RF meters, gain control, and receiver outputs that can be either direct or summed for flexible signal routing. With RF cascade and two Ethernet ports, units easily can share RF signal and be networked together for simplified frequency coordination and deployment. For networked audio applications, Dante digital networking allows multiple channels of audio to be transmitted and received over a single Ethernet cable. When more compatible frequencies over shorter distances, High Density mode can be enabled to dramatically increase the number of available open frequencies.


  • Two receivers in a rugged 1RU metal chassis with internal power supply
  • Individual gain controls, LED meters, and XLR outputs for each channel
  • Up to 64 MHz tuning range (region dependent)
  • Digital predictive switching diversity
  • High Density mode optimizes ULX-D systems to simultaneously operate significantly more channels in applications up to 30 meters
  • RF cascade ports allow distribution of RF signal to another unit
  • Optimized scanning automatically finds, prioritizes, and deploys the cleanest frequencies to transmitters over IR sync
  • Bodypack frequency diversity ensures uninterrupted audio for mission-critical applications
  • AES 256-bit encryption-enabled for secure transmission
  • Audio summing routes both audio channels to each XLR receiver output
  • Dante digital networked audio over Ethernet
  • Up to 60 dB independently adjustable gain for each channel
  • Ethernet networking for streamlined frequency coordination and deployment across multiple receivers
  • Wireless Workbench 6 (WWB6) software integration for advanced coordination, monitoring, and control
  • AMX/Crestron control
  • AXT600 Axient Spectrum Manager compatible
  • Yamaha device ID allows simplified channel patching on CL consoles
  • Intuitive front panel LCD menu and controls with lockout feature
  • Audio and RF LED meters with peak indicator
  • XLR connectors with switchable mic/line output level
  • Remoteable 1/2 wave antennas


SPECIFICATIONS

General

  • Power Requirement: 100 to 240 V AC, 50-60 Hz, 0.26 A max
  • Dimensions (H x W x D): 1.7 x 19 x 10.8 inches/44 x 482 x 274 mm
  • Weight: 7.4 lbs (3.36 kg), without antennas
  • Housing: Steel; Extruded Aluminum

Audio Output

  • Gain Adjustment Range: −18 to +42 dB, in 1 dB steps (plus Mute setting)
  • Configuration: XLR balanced (1=ground, 2=audio +, 3=audio -)
  • Impedance: 100 Ω
  • Full Scale Output
    • LINE setting: +18 dBV
    • MIC setting: −12 dBV
  • Mic/Line Switch: 30 dB pad
  • Phantom Power Protection: Yes

Cascade Output

  • Connector Type: BNC
  • Configuration: Unbalanced, passive
  • Impedance: 50 Ω
  • Insertion Loss: 0 dB

Networking

  • Network Interface: Dual Port Ethernet 10/100 Mbps, 1Gbps, Dante Digital Audio
  • Network Addressing Capability: DHCP or Manual IP address
  • Maximum Cable Length: 100 m (328 feet)

RF Input

  • Spurious Rejection: greater than 80 dB, typical
  • Connector Type: BNC
  • Impedance: 50 Ω
  • Bias Voltage: 12 to 13 V DC, 150 mA (maximum, per antenna)

Manufacturer: Shure
Model: ULXD4D=-G50
SKU: I291056-N-9-WHXB
UPC: 042406214155
