Tascam Model 12 All-In-One Desktop Production Suite
MSRP: $89900
Couldn't load pickup availability
About Inventory Status
About Inventory Status
Questions? Call or text us at 301-946-8808.
♫ In stock: It is in stock and available to ship or pickup. Apparel must be shipped from another location and is not available for in-store pickup. We can usually ship or have these items available for pickup by the next business day if they don't require inspection, special handling, or setup. Our pickup location is 11151 Veirs Mill Rd. Silver Spring, MD 20902.
📆 Preorder: It is on the way to our warehouse. We can't predict when preorder items will arrive due to current supply chain issues. If you place an order for one of these items someone will contact you to estimate the delivery date.
❓ Out of stock: We don't currently have it available but you're not out of luck yet. We still may be able to get it. If you order one of these items we will contact you with an estimated fulfillment date. You have the option to cancel the order if you change your mind.
❔ Special order: The item is so special that it needs to be custom ordered for you. Some of these items are works of art and have to be made individually. Orders for special order items must be prepaid and we cannot accept cancellations or refunds.
█ Sold out: We don't think we can get this item because it was either discontinued by the manufacturer or was limited in quantity. If you want or need this item call or text us. Sometimes we can help you track down the item through other sources or help you find something similar.
About Item Conditions
About Item Conditions
Questions? Call or text us at 301-946-8808.
New: The item is brand new as received from the manufacturer with a full manufacturer warranty. Instruments such as guitars, snare drums, drum kits, brass and woodwind instruments may be opened for photography and quality control inspection and may not be in a factory sealed box.
Mint or Open Box: The item may have been opened and tested but has been repackaged. The original packaging may have superficial issues but the item itself and any originally included accessories are in perfect, like new condition.
Display Model: These items are so cool that we put them on display in our legendary shop. The condition is brand new as received from the manufacturer with manufacturer warranty. Rest assured, these items undergo a very careful inspection before shipping.
Demo: These items have been on our sales floor for demo purposes and will likely show signs of use. The original packaging may no longer be included, but you can be assured that you are receiving an awesome item and an awesome price.
Used: The item is used. These item may have varying degrees of wear. Please read the description for information about the condition of the item. Used items do not carry a warranty.
B or C Stock: Factory refurbished. These items were purchased from the manufacturer in a refurbished condition. They will show some cosmetic issues, but nothing that would impact performance. Being that these are sealed from the manufacturer, we generally do not open these to photograph the cosmetic issues. They are guaranteed to work and may have a limited warranty or you may purchase an extended warranty in some cases. Please see the listing description for item specific information.
Description
Description
The Tascam Model 12 Integrated Production Suite is the Ultimate Desktop Tool for Music and Multimedia Creators
TASCAM's Model 12 is a compact all-in-one integrated mixer designed for music and multimedia creators, songwriters and performers. Features include TASCAM's critically acclaimed multi-track recorder, USB audio/MIDI interface, DAW control functions, and unique podcasting capability including mix-minus and smartphone inputs. The Model 12 supports your creative process, production, and workflow from start to finish including podcasting.
- 10 inputs (8 Monaural XLR mic inputs [+48V support])/10 TRS line inputs) and Bluetooth® 5.0 input, 3.5mm (1/8") TRRS input (for Smartphone)
- TASCAM Ultra HDDA Mic Pre-amp technology (CH 1 thru 6)
- 1-knob compressor and 3 band EQ installed on all input modules
- Equipped with 60mm faders
- Selectable PFL/AFL modes and the in-place solo (SIP)
- Stereo output to MAIN L-R and SUB L-R, monaural send to AUX1 and AUX2
- Dual headphone output with individual volume and source selection
- TASCAM FX equipped
- Recording function with punch in/out support allows direct SD card 12 track recording / 10 track playback
- 12 in / 10 out USB audio interface function (USB Type-C connector)
- Built-in metronome function
- Bluetooth® 5.0 input with AAC and SBC codec support
- Equipped with MIDI IN/OUT connectors, USB-MIDI interface function, and MTC output/MIDI clock output with SPP support
- Supports simple DAW control (HUI/MCU protocol emulation)
- Click output with TAP TEMPO support
- Dual footswitch (TRS connector) function allows assignment of transport, FX, etc
- Smartphone input with mix-minus function
SPECIFICATIONS
General
- Power: AC 100 to 240V, 50/60Hz
- Power Consumption: 16W
- Dimensions (W x H x D): 13.5 x 14.2 x 3.9 inch / 343 × 360 × 98.8 mm (including knob height and protrusion)
- Weight: 9.5 lb / 4.3 kg
- Operating Temperature: 5 to 35 °C / 41 to 95 °F
- Include Items: AC adapter, USB Type-C to A cable, TRRS cable, Owner's manual (with warranty)
Recording
- Supported Media: SD (512MB to 2GB), SDHC (4GB to 32GB), SDXC (64GB to 512GB), Class 10 or higher required
- File System
- SD card: FAT16
- SDHC card: FAT32
- SDXC card: exFAT
- Recording File Format: WAV(BWF)
- Playback Format: WAV, BWF
- Sampling Frequency: 44.1k / 48k Hz
- Bit Depth: 16 / 24 bit
- Maximum Recordable Channel Number: 12ch (10ch + 2 stereo mix)
Audio Inputs
- MIC IN: CH1 to 6, 7, 9
- Connector: XLR 3-31 (1: GND, 2: HOT, 3: COLD, Balanced)
- Maximum Input Level: +10dBu
- Nominal Input Level: -8dBu
- Minimum Input Level: -58dBu
- Gain Adjustable Range: 0 to 50dB
- Input Impedance: 1.8k ohm
- Phantom Power Supply: +48V
- LINE IN: CH1 to 6, 7/8, 9/10
- Connector: 1/4" (6.3mm) TRS Phone jack (T: HOT, R: COLD, S: GND, Balanced)
- Maximum Input Level: +22dBu
- Nominal Input Level: +4dBu
- Gain Adjustable Range: -10 to +40 dB (CH 1 to 6), -20 to +30 dB (CH 7/8 and 9/10)
- Input Impedance: 22k ohm
- INST IN: CH1 to 6, 7, 9
- Connector: 1/4" (6.3mm) TS Phone jack (T: HOT, R: GND, S: GND, Unbalanced)
- Maximum Input Level: +13.8dBV
- Nominal Input Level: -4.2dBV
- Gain Adjustable Range: -10 to +40 dB (CH 1 to 6), -20 to +30 dB (CH 7 and 9)
- Input Impedance: 1M ohm
- INSERT: CH 1 and 2
- Connector: 1/4" (6.3mm) TRS Phone jack (T: Send, R: Return, S: GND)
- Return (Ring)
- Maximum Input Level: +18dBu
- Nominal Input Level: 0dBu
- Input Impedance: 5k ohm
- Send (Tip)
- Maximum Output Level: +18dBu
- Nominal Output Level: 0dBu
- Output Impedance: 100 ohm
- MUSIC/TALK: CH 9/10
- Connector: 1/8" (3.5mm) TRRS jack (for Smartphone, Unbalanced)
- Maximum Input Level: +8dBV
- Nominal Input Level: -10dBV
- Input Impedance: 10k ohm
Outputs
- MAIN OUTPUT
- Connector: XLR 3-32 (1: GND, 2: HOT, 3: COLD, Balanced)
- Maximum Output Level: +22dBu
- Nominal Output Level: +4dBu
- Output Impedance: 200 ohm
- SUB OUT, AUX OUT
- Connector: 1/4" (6.3mm) TRS Phone jack (T: HOT, R: COLD, S: GND, Balanced)
- Maximum Output Level: +16dBu
- Nominal Output Level: -2dBu
- Output Impedance: 200 ohm
- PHONES OUT: PHONES 1 and 2
- Connector: 1/4" (6.3mm) Stereo Phone jack
- Maximum Output Level: 45mW + 45mW (32 ohm loaded)
Other Connections
- FOOTSWITCH: Compatible with TASCAM RC-1F Foot Switch
- Connector: 1/4" (6.3mm) TRS Phone jack
- CLICK: Metronome click
- Connector: 1/4" (6.3mm) TRS Phone jack
- USB Audio: For connection with PC
- Connector: USB Type-C
- Format: USB2.0 High-Speed, Mass-storage class/USB Audio Class
- Sampling Rate: 44.1k / 48k Hz
- Bit Depth: 16 / 24 bit
- Maximum INPUT: 12ch
- Maximum OUTPUT: 10ch
- Bluetooth®: To MAIN or CH 9/10
- Version: 5.0
- Output Class: Class 2 (Transmission range: approx. 33 ft. / 10 m)
- Supported Profile: A2DP
- Supported A2DP Codecs: SBC, AAC
- A2DP Content Protection: SCMS-T
EQ and Effects
- Channel EQ
- Low-Cut: 100Hz, -18dB / Octave
- Hi-Shelving: +15dB / -15dB, Cut off frequency = 10kHz
- Mid-Peaking: +15dB / -15dB, 100Hz to 8kHz Variable, MID Band Q Fix, 0.5
- Low-Shelving: +15dB / -15dB, Cut off frequency = 80Hz
- Master EQ
- Hi-Shelving: +15dB / -15dB, Cut off frequency = 10kHz
- Mid-Peaking: +15dB / -15dB, 100Hz to 8kHz Variable, Q: 0.5/5
- Low-Shelving: +15dB / -15dB, Cut off frequency = 60Hz
- Internal Effects
- HALL 1, HALL 2, ROOM 1, ROOM 2, PLATE, STUDIO, LIVE, DELAY 1, DELAY 2, PING PONG, CHORUS, FLANGER, DELAY + HALL 1, DELAY + HALL 2, CHORUS + HALL 1, CHORUS + HALL 2
Audio Performance
- Frequency Response: 20Hz to 20kHz (+0.3/-0.7 dB, MIC IN to MAIN OUT)
- S/N Ratio: 103dB (MAIN OUT, MAIN fader: nominal position)
- Equivalent Input Noise: -128dBu (Mono Input Channel, Rs: 150Ω, GAIN knob: Max)
- Total Harmonic Distortion: 0.003% (MIC IN to MAIN OUT, nominal input level, +2dBu, 1kHz, GAIN min.)
- Crosstalk: -95dB, channels / input and output (1kHz, PAN fully counter clockwise / fully clockwise)
- Maximum Gain
- 74dB (MIC to MAIN OUT)
- 54dB (MIC to INSERT OUT)
- 74dB (MIC to SUB OUT)
- 75dB (MIC to AUX 1/2 OUT)
- 24dB (USB/SD to MAIN OUT)
- (EQ flatten, PAN fully counter clockwise / fully clockwise)
Compatibility
- Windows
- Compatible Computers: Windows-compatible computer with a USB2.0 port
- OS: Windows 10, Windows 8.1, Windows 7
- CPU: Dual core / 2GHz or faster
- Memory: 2GB or more
- Driver: USB Audio Class 2.0, ASIO2.0, WDM (MME)
- Screen Resolution: 1280 × 800 Dots or more
- Mac
- Compatible Computers: Apple Mac computer with a USB2.0 port
- OS: macOS Big Sur, macOS Catalina, macOS Mojave, macOS High Sierra (10.13)
- CPU: Dual core / 2GHz or faster
- Memory: 2GB or more
- Driver: Core Audio
- Screen Resolution: 1280 × 800 Dots or more
- iOS/iPadOS
- OS: iPadOS 14, iOS 14, iPadOS 13, iOS 13, iOS 12, iOS 11
- Driver: Core Audio
Manufacturer: Tascam
Model: MODEL 12
SKU: I649188-N-1-WHXA
UPC: 043774034499
