Viscount Votex 315 Rotary Speaker

Sold out
Original price $2,990.00 - Original price $2,990.00
Original price
$2,990.00
Default Title: $2,990.00
Current price $2,990.00
About Inventory Status


Questions?
Call or text us at 301-946-8808.

In stock: It is in stock and available to ship or pickup. Apparel must be shipped from another location and is not available for in-store pickup. We can usually ship or have these items available for pickup by the next business day if they don't require inspection, special handling, or setup. Our pickup location is 11151 Veirs Mill Rd. Silver Spring, MD 20902.

📆 Preorder: It is on the way to our warehouse. We can't predict when preorder items will arrive due to current supply chain issues. If you place an order for one of these items someone will contact you to estimate the delivery date.

Out of stock: We don't currently have it available but you're not out of luck yet. We still may be able to get it. If you order one of these items we will contact you with an estimated fulfillment date. You have the option to cancel the order if you change your mind.

Special order: The item is so special that it needs to be custom ordered for you. Some of these items are works of art and have to be made individually. Orders for special order items must be prepaid and we cannot accept cancellations or refunds.

█ Sold out: We don't think we can get this item because it was either discontinued by the manufacturer or was limited in quantity. If you want or need this item call or text us. Sometimes we can help you track down the item through other sources or help you find something similar.

About Item Conditions


Questions?
Call or text us at 301-946-8808.

New: The item is brand new as received from the manufacturer with a full manufacturer warranty. Instruments such as guitars, snare drums, drum kits, brass and woodwind instruments may be opened for photography and quality control inspection and may not be in a factory sealed box.

Mint or Open Box: The item may have been opened and tested but has been repackaged. The original packaging may have superficial issues but the item itself and any originally included accessories are in perfect, like new condition.

Display Model: These items are so cool that we put them on display in our legendary shop. The condition is brand new as received from the manufacturer with manufacturer warranty. Rest assured, these items undergo a very careful inspection before shipping.

Demo: These items have been on our sales floor for demo purposes and will likely show signs of use. The original packaging may no longer be included, but you can be assured that you are receiving an awesome item and an awesome price.

Used: The item is used. These item may have varying degrees of wear. Please read the description for information about the condition of the item. Used items do not carry a warranty.

B or C Stock: Factory refurbished. These items were purchased from the manufacturer in a refurbished condition. They will show some cosmetic issues, but nothing that would impact performance. Being that these are sealed from the manufacturer, we generally do not open these to photograph the cosmetic issues. They are guaranteed to work and may have a limited warranty or you may purchase an extended warranty in some cases. Please see the listing description for item specific information.

Educational & Government Sales Quotes

Click here to inquire about an educational or government quote and discover more about our Educational & Government Sales Division.


Elevate Your Sound Experience with the Viscount Votex 315 Rotary Speaker

Vortex 315 is a 2 amplified channels rotary speaker composed by a woofer with rotating drum and a driver with rotating horn, specifically designed in collaboration with Silvio Della Mattia, to reproduce the original rotary horn speakers. This system of sound amplification and diffusion became popular with the advent of the electromechanical organ and consisted of two sections, one dedicated to high tones (horn) and another concerning low tones (drum), which could rotate at different speeds and which produce a particular three-dimensional effect due to the rotation of the loudspeakers. This effect is the result of the sum of the Doppler effect, due to the relative displacement of the sound sources with respect to the listener, and the sound reflections resulting from the rotation.

The front panel gathers the main controls for quick speaker set-up, such as choosing the stop position (Brake), adjusting the horn rotation speed, EQ, volume, selecting one of the 6 tone response presets, and the connection connectors.

Slow / Fast rotation speeds or Brake are selectable via the lever control of your Legend or Legend Soul connected to the 11-pin connector, or via a foot-switch pedal or MIDI. Also available for free download is the Windows and Mac Os (also iOs) compatible Vortex Editor application, which allows fine tuning of the most important configuration parameters. Vortex 315 is the perfect speaker to connect to your Legend Soul, or any other organ, bringing that vintage style that will make the difference.


SPECIFICATIONS

  • Type: 2 amplified channels (woofer with rotating drum + driver with rotating horn)
  • Power (W): 300W Upper 80W and Lower 220W
  • Crossover Frequency: 800Hz
  • Subsonic filter: Yes
  • HF Protection: compressor, short circuit, thermal
  • PC Control: Yes
  • Connections: 3 pins IEC 250 VAC, 1x unbalanced input jacks, jack pedal, USB B TYpe, MIDI IN, UNDECAL 11 pin connector
  • Controls: Volume, Equalizer (bass - mid gain - mid frequency - treble), 11 pin input sensitivity, FACTORY RESET, rotative presets selector
  • Engine Controls: The led is: off when the motors are brake; yellow when the motors are slow; red when the motors are fast. You can brake (independently from the horn) the rotor bass by it’s switch. Choose the rotations of the horn on three speed by its switch. Choose the horn position when it’s brake, if rear or random.
  • Speakers: 1x15" Woofer, PA Driver with rotating horn
  • Cabinet: Plywood
  • Protection: Metal grids
  • Dimensions (WxHxD): cm 52 x 75 x 48 - 20.4" x 29.5" x 18.9"
  • Weight: 27 Kg - 59 Lbs


Manufacturer: Viscount Organs
Model: 9A13LEGVORTEX315
SKU: I715755-N-0-WHXB
