Yamaha CHR12M V2 12-Inch Passive Floor Monitor

Step Up Your Sound with the Yamaha CHR12M 12-Inch Floor Monitor

The CHR12M is a 2-way loudspeaker with a 12-inch woofer and a 1.75-inch HF driver in a space saving coaxial configuration, perfect for use as a floor monitor. Combining carefully selected and customized transducers with the same plywood construction found on Yamaha’s high-end CZR Series, the CHR12M offers best-in-class sound quality and durability.

• The coaxial driver delivers precise, smooth phase and frequency response characteristics ideal for use in monitoring applications
• Featuring a plywood cabinet that delivers a clear sound with minimal vibration
• Compact, low profile, plywood enclosure with a polyurea coating for a robust, scratch-resistant surface
• A pole socket for use on a stand
• Yamaha DSP equipped amplifiers or other compatible signal processors have dedicated speaker processor tuning settings to maximize system performance

SPECIFICATIONS

• Speaker Type: 2-way Speaker, Bass-reflex
• Frequency Range (-10 dB): 61 Hz - 20 kHz
• Coverage Area: H90° x V90°
• Crossover: 1.8 kHz
• Nominal Impedance: 8 Ω
• SPL
• Sensitivity (1W; 1m on axis): 93 dB SPL
• Peak (Calculated): 123 dB SPL
• Components
• LF: Diameter: 12" cone, Voice Coil: 2.5", Magnet: Ferrite
• HF: Diaphragm: 1.75", Type: 1" throat coaxial compression driver, Magnet: Ferrite
• Power Rating
• NOISE: 250 W
• PGM: 500 W
• PEAK: 1000 W
• I/O Connectors: SpeakON NL4MP x 2 (Parallel)
• Handle: Side x1
• Pole Socket: Φ35 mm x1 (Bottom)
• Floor Monitor Angle: 57°
• Dimensions (W x H x D): 19.7 x 13.5 x 17.9 inch / 500 x 343 x 454 mm
• Weight: 34.4 lb / 15.6 kg
