Yamaha MG12XU 12-Channel Mixer
1/4
SKU

Yamaha

Yamaha MG12XU 12-Channel Mixer

$375.99 USD
Sale price  $375.99 USD Regular price  $375.99 USD

MSRP:$59800

Promotional Pricing Through December 31

Save $94! Was $469.99

In stock and ready to ship or pick up.

Condition: New

Store pickup

Yamaha MG12XU 12-Channel Mixer

Chuck Levin's Washington Music Center

Usually ready in 2-4 days

11151 Veirs Mill Rd
Wheaton, MD 20902

PRODUCT DETAILS

Yamaha MG12XU 12-Channel Mixer


The Yamaha MG12XU 12-Channel Mixer is Tough Enough to Travel and Sound Enough For Studios

For more than a century, Yamaha has been building a legacy of superior craftsmanship and innovation exemplified in all of their products, from an unrivalled catalog of world-class musical instruments to touring-grade professional audio. Now in its third incarnation, the MG Series embodies this pursuit of design excellence, and incorporates some of the same technologies developed for use in high-end professional consoles, including studio-quality preamps, powerful digital processing, and a rugged, reliable construction.

With an intuitive, easy-to-use interface, the MG Series boasts an extensive lineup of compact mixing consoles with models ranging from six to twenty channels, suitable for a diverse range of users and applications. For installed, recording, or live music settings, the solid construction and flexible design of these consoles lets you shape your sound with confidence, continually delivering peak performance and a level of sound quality and reliability unrivalled in its class.


  • 12-Channel Mixing Console
  • Max. 6 Mic / 12 Line Inputs (4 mono + 4 stereo)
  • 2 GROUP Buses + 1 Stereo Bus
  • 2 AUX (incl. FX)
  • "D-PRE" mic preamps with an inverted Darlington circuit
  • 1-Knob compressors
  • High-grade effects: SPX with 24 programs
  • 24-bit / 192kHz, 2in / 2out USB Audio functions
  • Works with the iPad (2 or later) through the Apple iPad Camera Connection Kit / Lightning to USB Camera Adapter
  • Includes Cubase Al DAW software download version
  • PAD switch on mono inputs
  • +48V phantom power
  • XLR balanced outputs
  • Internal universal power supply for world-wide use
  • Optional Rack Mount Kit RK-MG12 Available
  • Metal chassis


SPECIFICATIONS

  • Onboard Processing
    • SPX Algorithm: 24 programs
    • PARAMETER Control: 1
    • FOOT SW: 1 (FX RTN CH on/off)
  • I/O
    • Phantom Power: +48V
    • Digital I/O: USB 2.0 class compliant, 24-bit / 192 kHz
  • Input Channels
    • Mono [MIC/LINE]: 4
    • Mono/Stereo [MIC/LINE]: 2
    • Stereo [LINE]: 2
  • Input Channel Functions
    • PAD
    • HPF
    • COMP
    • EQ HIGH
    • EQ MID
    • EQ LOW
    • PEAK LED
    • Level Meter
  • Output Channels
    • STEREO OUT: 2
    • MONITOR OUT: 1
    • PHONES: 1
    • AUX SEND: 2
    • GROUP OUT: 2
  • Bus
    • Stereo: 1
    • GROUP: 2
    • AUX: 2 (incl. FX)
  • Total Harmonic Distortion: 0.03 % @ +14dBu (20 Hz to 20kHz), GAIN knob: Min, 0.005 % @ +24dBu (1kHz)
  • Frequency Response: +0.5 dB/-1.5 dB (20 Hz to 48 kHz) , refer to the nominal output level @ 1 kHz, GAIN knob: Min
  • Equivalent Input Noise: -128 dBu (Mono Input Channel, Rs: 150Ω, GAIN knob: Max)
  • Residual Output Noise: -102 dBu (STEREO OUT, STEREO master fader: Min)
  • Crosstalk: -78 dB
  • Power Requirements: AC 100 – 240 V, 50 / 60 Hz
  • Power Consumption: 22 W
  • Dimensions (W x H x D): 12.1 x 4.6 x 16.6 inches / 308 x 118 x 422 mm
  • Net Weight: 9.3 lbs / 4.2 kg
  • Operating Temperature: 0 to +40˚ C
  • Included Accessories
    • Owner's Manual
    • Technical Specifications
    • AC power cord
    • Cubase AI Download Information


Manufacturer: Yamaha
Model: MG12XU
SKU: I313064-N-6-WHXA
UPC: 086792990583
